400 Series
Hubbell’s POLYCAST® 400 Series is a polymer concrete trench drain system designed for light traffic applications such as sidewalks, patios and tennis courts. The 400 Series’ non-sloped channels are fitted with galvanized steel slotted grates that can withstand the weight of light vehicles such as lawnmowers and golf carts. The slotted steel grates are bicycle-safe making them pedestrian friendly.

500 Series
The POLYCAST® 500 Series is Hubbell’s low-profile drainage system. At 1.75″ deep, the 500 Series polymer concrete channels are shallow enough to be used in raised concrete platforms such as parking garages and concrete patios. Drain channels come standard in 48″ lengths and have 4″ bottom drill-out indented areas for positioning outlets for pipe connections.

600 Series
Hubbell’s POLYCAST® 600 Series is one of the most prominent small commercial drains on the market. The 6.25″ wide (OD) polymer concrete channels have a built-in .65 percent slope that allows the system to achieve flow rates of 470 GPM, higher than drainage systems of similar size. Channels are offered in 48″ and 24″ lengths. Channel edge protectors are available in galvanized steel and stainless steel. POLYCAST® 600 Series also offers extender rails to increase the length of a trench drain run. The 600 Series is also available in vinyl ester material for chemical and high heat resistance.

700 Series
Hubbell’s POLYCAST® 700 Series is the logical trench drain choice for heavy duty applications with constant fork trucks or heavy equipment. The POLYCAST® 700 features 6.25″ wide (OD) polymer concrete channels with a 0.6% built-in slope that offers flow rates of 470 GPM. POLYCAST® 700 is based on the 600 series channel, and so shares many of the features that make POLYCAST® 600 a prominent small commercial drain.

800 Series
The POLYCAST® 800 MAXI heavy duty drainage system is a high-volume trench drain designed to handle heavier weights than the POLYCAST® 600 Series. At twice the width of its smaller commercial cousin, the POLYCAST® 800 Series is meant to intercept higher flow rates in high-volume areas. The 48″ long 800 Series channels feature an 8″ inside with radiused bottom and neutral slope. The drain system’s corrosion resistant channel bodies act as a containment system for industrial and chemical applications.

900 Series
The POLYCAST® 900 Series is the nations premier transportation industry trench drain system. With over 25 years of service, this system has proven itself time and time again as the industry standard.

TDS Products for POLYCAST® 600
Trench Drain Systems acknowledged the need for a variety of products to complement the POLYCAST®600 drainage system. Polymer concrete end caps, outlets, a universal catch basin and more.

POLYCAST® Catch Basins
The POLYCAST® 650/750 , 651/751 and 653/753 catch basins offer large catch basin sizes with many different configurations. With different edging, frame and grate options, these catch basins are perfect for your POLYCAST® run and projects. From a 12″-24″ to a 24″-24″ size, these catch basins are ready to handle your heavy duty applications.
