Fiberglass Grates

Custom Fiberglass
Fiberglass is a cost-effective material when it comes to the grating. This strong, lightweight material is easily fabricated into grating for custom drain applications. Its corrosion and chemical resistance puts it in a class with stainless steel while being more economical. Consider using fiberglass grating in kennel drains, kitchen drains or drains exposed to salt water/coastal environments.
Molded Fiberglass
Fiberglass grating can be molded into large sheets for later fabrication into smaller, custom shapes. Mesh grating is made by laying fiber reinforcing materials in grid work-shaped mold and bonding them with polyester or vinyl ester resins. Other resins are available for special applications. The molded product is ground to the desired thickness and flatness. Slip-resistant coatings are applied to the surface at this time if required. Trench Drain Systems offers the following molded fiberglass grating products.
Pultruded Fiberglass
Pultrusion is a fiberglass forming process whereby reinforcing fibers are pulled through an extrusion die while vinyl ester polymer resins are extruded under pressure. The act of “pulling” fiber while “extruding” resin leads to the term “pultrusion”. Fiberglass shapes made by this process come in long, continuous shapes. In the case of fiberglass grating, the shapes have cross-sections akin to rectangular bars, tees and I’s. To make bar grating, these long bars are assembled parallel to each other and connected by structural cross members (known as tie bars) on 6″ spacing. A non-slip coating is applied to the grating after assembly.
Considerations
- Customize the Size
Fiberglass offers the flexibility to have your grates custom-made into the size you need no matter how unique it may be.
- No Scrap
Avoid theft of grates for scrap metal by using fiberglass grating. Contact our experts to help you determine the best option for your project.
- Heavy Duty
Fiberglass offers heavy-duty strength with a fraction of the weight. It is also nonabsorbent and won’t hold odors.
- Time is Money
In many cases, fiberglass grates can be sent out within 24 hours if not the same day!
- Safe & Eco Friendly
Fiberglass has low thermal and electrical conductivity and is safer for the environment.
Product Recommendations
-
WYE Rail Frames for 1" or 1.5" Thick Grates - FGK-WYE-1015
WYE Rail Frames for 1" or 1.5" Thick Grates - FGK-WYE-1015
ULMA HYDROPLUS Mini with 488 Fiberglass bar grate - Load Class C
ULMA HYDROPLUS Mini with 488 Fiberglass bar grate - Load Class C
ULMA HYDROPLUS Mini with 486 Fiberglass Grate - Load Class B
ULMA HYDROPLUS Mini with 486 Fiberglass Grate - Load Class B
TP0650S (Shallow) Catch Basin Kit w/ DG0644SPH for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644SPH for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644SPH & Stainless Edge for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644SPH & Stainless Edge for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644H for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644H for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644H & Stainless Edge for POLYCAST®
TP0650S (Shallow) Catch Basin Kit w/ DG0644H & Stainless Edge for POLYCAST®
TDS FG1245 Class A 1.5" Sq. Mesh Fiberglass 14" x 48" Grate
TDS FG1245 Class A 1.5" Sq. Mesh Fiberglass 14" x 48" Grate
TDS FG1244 Class C Mesh Fiberglass 14" x 48" Grate
TDS FG1244 Class C Mesh Fiberglass 14" x 48" Grate
TDS DG3045 Class B Fiberglass 1.5" Sq. Mesh 8" x 48" Grate
TDS DG3045 Class B Fiberglass 1.5" Sq. Mesh 8" x 48" Grate
TDS DG3044 Class C VE Fiberglass I-Bar with Grit 8" x 48" Grate
TDS DG3044 Class C VE Fiberglass I-Bar with Grit 8" x 48" Grate
TDS DA3000S Bottom Outlet | 3000 Series
TDS DA3000S Bottom Outlet | 3000 Series
TDS DA3000A End Cap/Adapter | 3000 Series
TDS DA3000A End Cap/Adapter | 3000 Series
SS600 Stainless Steel Drain Kit w/ DG0644SP Fiberglass Bar Grate | Class C
SS600 Stainless Steel Drain Kit w/ DG0644SP Fiberglass Bar Grate | Class C
SS600 Stainless Steel Drain Kit w/ DG0644 Fiberglass Bar Grate | Class B
SS600 Stainless Steel Drain Kit w/ DG0644 Fiberglass Bar Grate | Class B
POLYCAST DG0644SPH Class C Spacing 3/8" Fiberglass BAR 6" x 24" Grate
POLYCAST DG0644SPH Class C Spacing 3/8" Fiberglass BAR 6" x 24" Grate
POLYCAST DG0644SP Class C Spacing 3/8" Fiberglass BAR 6" x 48" Grate
POLYCAST DG0644SP Class C Spacing 3/8" Fiberglass BAR 6" x 48" Grate
POLYCAST DG0644H Class B Spacing 5/8" Fiberglass BAR 6" x 24" Grate
POLYCAST DG0644H Class B Spacing 5/8" Fiberglass BAR 6" x 24" Grate
POLYCAST DG0644 Class B Spacing 5/8" Fiberglass BAR 6" x 48" Grate
POLYCAST DG0644 Class B Spacing 5/8" Fiberglass BAR 6" x 48" Grate
MEArin 142000 Catch Basin with Sediment Basket
MEArin 142000 Catch Basin with Sediment Basket
FG-MICRO-CB18 Class A ADA Compliant 18" x 18" Grate - Dark GRAY
FG-MICRO-CB18 Class A ADA Compliant 18" x 18" Grate - Dark GRAY
FG-MICRO-CB12 Class A ADA Compliant 12" x 12" Grate - Dark Gray
FG-MICRO-CB12 Class A ADA Compliant 12" x 12" Grate - Dark Gray
FG-MICRO-CB09 Class A ADA Compliant 9" x 9" Grate - Dark Gray
FG-MICRO-CB09 Class A ADA Compliant 9" x 9" Grate - Dark Gray
FG-MICRO-1448 Micro Mesh Fiberglass ADA Compliant 14"X48" Grate Load Class C
FG-MICRO-1448 Micro Mesh Fiberglass ADA Compliant 14"X48" Grate Load Class C
FG-MICRO-1248 Micro Mesh Fiberglass ADA Compliant 12"X48"x1.5" Grate
FG-MICRO-1248 Micro Mesh Fiberglass ADA Compliant 12"X48"x1.5" Grate
FG-MICRO-0848 Micro Mesh Fiberglass ADA Compliant 8"X48" Grate Load Class C
FG-MICRO-0848 Micro Mesh Fiberglass ADA Compliant 8"X48" Grate Load Class C
FG-MESH-CB18 Class A Fiberglass 18" x 18" x 1" Catch Basin Grate - Dark Grey
FG-MESH-CB18 Class A Fiberglass 18" x 18" x 1" Catch Basin Grate - Dark Grey
FG-MESH-CB12 Class A Fiberglass 12" x 12" x 1" Catch Basin Grate - Dark Grey
FG-MESH-CB12 Class A Fiberglass 12" x 12" x 1" Catch Basin Grate - Dark Grey
FG-MESH-CB09 Class A Fiberglass 9" x 9" x 1" Catch Basin Grate - Dark Grey
FG-MESH-CB09 Class A Fiberglass 9" x 9" x 1" Catch Basin Grate - Dark Grey
FG-MESH-1448 Mesh Fiberglass 14"X48" x1.5" Grate Load Class C
FG-MESH-1448 Mesh Fiberglass 14"X48" x1.5" Grate Load Class C
FG-MESH-1248 Mesh Fiberglass 12"X48"x1.5" Grate Load Class C
FG-MESH-1248 Mesh Fiberglass 12"X48"x1.5" Grate Load Class C
FG-MESH-1048 Mesh Fiberglass 10" X 48"x1.5" Grate Load Class C
FG-MESH-1048 Mesh Fiberglass 10" X 48"x1.5" Grate Load Class C
FG-MESH-0848 Mesh Fiberglass 8"X48"x1.5" Grate Load Class C
FG-MESH-0848 Mesh Fiberglass 8"X48"x1.5" Grate Load Class C
FG-I4015-1548 Fiberglass I-Bar Grate 15"X48"x1.5" Grate Load Class C
FG-I4015-1548 Fiberglass I-Bar Grate 15"X48"x1.5" Grate Load Class C
FG-I4015-1248 Fiberglass I-Bar Grate 12"X48"x1.5" Grate Load Class C
FG-I4015-1248 Fiberglass I-Bar Grate 12"X48"x1.5" Grate Load Class C
FG-I4015-0948 Fiberglass I-Bar Grate 9"X48" Grate Load Class C
FG-I4015-0948 Fiberglass I-Bar Grate 9"X48" Grate Load Class C
FG-HLC-1448 Mesh Fiberglass 14"X48" Grate Load Class C
FG-HLC-1448 Mesh Fiberglass 14"X48" Grate Load Class C
FG-HLC-1248 Mesh Fiberglass 12"X48" Grate Load Class C
FG-HLC-1248 Mesh Fiberglass 12"X48" Grate Load Class C
FG-HLC-1048 Mesh Fiberglass 10" X 48" Grate | Load Class C
FG-HLC-1048 Mesh Fiberglass 10" X 48" Grate | Load Class C
FG-HLC-0848 Mesh Fiberglass 8"X48" Grate Load Class C
FG-HLC-0848 Mesh Fiberglass 8"X48" Grate Load Class C
EZ Frame Rails for 1" or 1.5" Thick Grates
EZ Frame Rails for 1" or 1.5" Thick Grates
9" Fiberglass Kit w/ T-Bar Grate and WYE Frame - Load Class C
9" Fiberglass Kit w/ T-Bar Grate and WYE Frame - Load Class C
9" Fiberglass Kit w/ T-Bar Grate and EZ Frame - Load Class C
9" Fiberglass Kit w/ T-Bar Grate and EZ Frame - Load Class C
9" Fiberglass Kit w/ I-Bar Grate and WYE Frame - Load Class C
9" Fiberglass Kit w/ I-Bar Grate and WYE Frame - Load Class C
9" Fiberglass Kit w/ I-Bar Grate and EZ Frame - Load Class C
9" Fiberglass Kit w/ I-Bar Grate and EZ Frame - Load Class C
9" Fiberglass Heel Proof T-Bar Grate - Load Class C
9" Fiberglass Heel Proof T-Bar Grate - Load Class C
8" Fiberglass Kit w/ Micro Mesh ADA Compliant Grate and WYE Frame - Load Class C
8" Fiberglass Kit w/ Micro Mesh ADA Compliant Grate and WYE Frame - Load Class C
8" Fiberglass Kit w/ Micro Mesh ADA Compliant Grate and EZ Frame - Load Class C
8" Fiberglass Kit w/ Micro Mesh ADA Compliant Grate and EZ Frame - Load Class C
8" Fiberglass Kit w/ Mesh Grate and WYE Frame - Load Class C
8" Fiberglass Kit w/ Mesh Grate and WYE Frame - Load Class C
8" Fiberglass Kit w/ Mesh Grate and EZ Frame - Load Class C
8" Fiberglass Kit w/ Mesh Grate and EZ Frame - Load Class C
